SDC0FF0I
Industrial I/O Control PCIe Card
16+16-ch Isolated Digital I/O
Board Level:
Digital I/O Communication:
- Designed to meet PCI Express Base Specification Revision 2.1.
- With high reliable SUNIX QiuNiu UART Digital-I/O controller.
- Plug-n-Play, I/O address and IRQ assigned by system.
- Ultra low power consumption (<1.5W) design for green environment and industrial application.
- High quality electronic components, low impedance and high stability ensure product quality and reliability.
- Support Microsoft Windows 10/11 with C and C# programming language sample code.
- Providing a customizable API platform to meet IoT application needs.
- Certified by CE, FCC, RoHS, and Microsoft approvals.
- Support both standard and Low profile bracket design to meet various PC chassis.
Digital I/O Communication:
-
Expands isolated eight (16) digital input channels with features for all channels.
- Support both NPN & PNP devices
- Support both dry and wet contact connections
- With digital filter for noise reduction
- Built-in 32-bit counter for all digital in channels
- Expands isolated eight (16) NPN type digital output channels with initial value (Booting & Restart) protection.
- Each channel built-in 2.5KV isolation protection for signal and power, allowing the input signals to be completely floated so as to prevent ground loops.
Introduction
SUNIX SDC0FF0I, industrial isolated Digital I/O PCI-Express add-on card, is designed for PC-based IoT Gateway or desktop that enables data acquisition and I/O control in the industrial automation. This board built-in SUNIX Digital-I/O controller, QiuNiu, and as well built with many of SUNIX advanced features and technologies. In addition, SUNIX provides API software and SDK library, allowing users to program under Windows 10/11 and Linux operating system. The software package includes a dynamic library.dll, as well as C, C# programming language sample codes, making it easier to develop application software. SUNIX PCI Express Industrial I/O Control Board enriches I/O expandable capacity with cost-efficient design; SDC0FF0I is the best digital I/O communicating solution to enrich your system I/O expandable capacity for lite industrial applications.
Features
Specifications
Board Communication
| Interface | PCI Express |
| Controller | SUNIX QiuNiu UART Digital-I/O Controller |
| BUS | PCI Express Gen1 x 1 (single lane) |
| IRQ & IO | Assigned by System |
| ESD Protection |
±15KV IEC61000-4-2 Air Gap Discharge ±8KV IEC61000-4-2 Contact Discharge |
Digital Input Communication
| Type | NPN & PNP |
| Channel | 16-channel |
| Dry Contact |
Logic Level 0: Open; Logic Level 1: Close to GND |
| Wet Contact |
Logic Level 0: 0 to 3VDC; Logic Level 1: 10 to 50VDC |
| Input Resistance | 10KΩ |
| Isolation | 2500 VDC |
| Frequency | Input Range 2KHz with Isolation |
| Pin Define | DI1~DI16, COM, GND |
| Counter | 32-bit counter for all channel |
| Interrupt Mode | Event trigger (Rising Edge, Falling Edge, Both modes) & polling for all channels |
| Noise Reduction | Digital Filter |
| PCB Connector | DB44 Female Connector |
Digital Output Communication
| Type | NPN |
| Channel | 16-channel |
| Voltage Range | 3.5 to 40VDC |
| Current | 500mA per Channel |
| Isolation | 2500 VDC |
| Pin Define | DO1~DO16, PWR, GND |
| Initial Protection | Initial Value Setup (Booting & Restart protection) |
| PCB Connector | DB44 Female Connector |
Software Support
| Microsoft |
Windows 10 (X86/X64) / 11 |
|
SDK |
Library: DLL for Windows supporting C, C++, C# languages. |
Regulatory Approvals
| Hardware |
CE / FCC / VCCI / BSMI |
Declaration
| Green Product |
RoHS, WEEE |
Environment
| Operation Temperature |
-20 to 70°C (-4 to 158°F) |
| Operation Humidity | 5 to 95% (non-condensing) |
|
Storage Temperature |
-20 to 70°C (-4 to 158°F) |
Dimension
| PCB Dimension |
120 x 68.5 mm |
| Bracket | Standard 120 mm / Low Profile 79.2mm |
|
Bracket Space |
1 |
Accessories
Including Accessories
DB44 Male DIN Rail Wiring Board
- 79.1 x 85.5mm
- Part No.:5DB44MDWBX0510-QCN
- 1 pcs.
DB44 to Male to Female Connection Cable
- 100 cm
- Part No.:1WDB-44M10044H1000
- 1 pcs.
Brackets Standard & Low Profile
- Standard 121 mm & Low Profile 79.2mm
- Bracket Space: 1
Support
Download Manual
| Manual | SDC0FF0I Manual |
|
| Version | Ver. 1.3 | |
| Update | 2022-08-18 19:50:14 | |
| Size | 1.7MB |
Download Datasheet
| Datasheet | SDC0FF0I Datasheet EN |
|
Download Guide
| Guide | Industrial Digital I/O Card Quick Installation Guide |
|
Download Driver
| Driver | Windows SDC IO Manager V1.0.1.0_20240703 | |
| Version | 1.0.1.0 | |
| Update | 2024-07-05 11:30:35 | |
| Size | 70.7MB | |
| OS |
Windows 11 23H2 64 bit
Windows 11 22H2 64 bit
Windows 10 22H2 (22H2) 32/64 bit
Windows 10 21H2 (21H2) 32/64 bit
Windows 10 21H1 (21H1) 32/64 bit
Windows 10 20H2 (20H2) 32/64 bit
|
| API | Windows SDC API V1.0.1.0_20240906 | |
| Version | 1.0.1.0 | |
| Update | 2024-09-09 09:35:00 | |
| Size | 24.2MB | |
| OS |
Windows 11 64bit
Windows 10 32/64 bit
|
| Driver | Linux SDC Expansion Board Driver V2.1.0.0_20240820 | |
| Version | V2.1.0.0 | |
| Update | 2024-08-20 10:44:49 | |
| Size | 10.3MB | |
| OS |
Linux Kernel 6.x
Linux Kernel 5.x
Linux Kernel 4.11 above
|
