Application of SUNIX CAN FD Card in Automotive Repair Station Diagnostic Systems
1. Introduction
As vehicle electronic systems become increasingly complex, traditional CAN communication can no longer meet the high-frequency, high-data-volume diagnostic requirements. CAN FD (Flexible Data-rate) technology offers higher data transfer rates and larger data payloads, becoming the mainstream choice for modern vehicle diagnostics.
CAN FD technology was developed to overcome the limitations of the traditional CAN protocol, primarily enhancing data rate and transmission efficiency. It is particularly suitable for next-generation vehicle electronic architectures. While other competing solutions on the market offer certain functionalities, SUNIX’s CAN FD card demonstrates clear differentiation with its high stability, low latency, and multi-channel support.
SUNIX’s CAN FD card is specifically designed for automotive repair station diagnostic systems, effectively improving fault diagnosis efficiency and maintenance accuracy.
二、應用場景
2. Application Scenarios
| Application Scenario | Function Description |
|---|---|
| ECU Fault Diagnosis | Quickly read and interpret ECU messages, supporting diagnostic protocols such as UDS and KWP2000 |
| Real-time Data Monitoring | Capture CAN FD signals at high speed, supporting multi-channel synchronous monitoring, suitable for dynamic testing and road test analysis |
| Maintenance Process Optimization | Integrate diagnostic tools with maintenance workflow to reduce manual errors and improve maintenance efficiency |
| Custom Report Generation | Convert diagnostic results into visual reports for better communication with technicians and customers |
| Multi-Vehicle Support | Compatible with various OEM CAN FD architectures, supporting both OEM and aftermarket diagnostic needs |
3. Technical Advantages
-
Proprietary Chip: Superior performance with streamlined unnecessary processes
-
Software Optimization: Driver / Application SDK / SocketCAN enhancements
-
Broad Support: Windows / Linux / Python / Node-RED
-
CAN FD: More flexible data rate, with transmission capacity eight times higher than the previous generation
-
Cross-Platform: x86, NXP i.MX6 & i.MX8, Rockchip, NVIDIA Jetson
4. Integration Recommendations
4-1 System Architecture Diagram
4-2 Recommended Actions
-
Install the CAN FD card in the diagnostic computer, selecting the appropriate interface based on requirements.
-
Install SUNIX’s dedicated drivers and SDK, and perform regular updates to ensure system compatibility and optimized performance.
-
Key Operation Points: Ensure proper grounding and signal line configuration during installation to avoid interference; installation and configuration are recommended to be performed by trained professionals.
5. Benefit Analysis
| Benefit Item | Description |
|---|---|
| Reduced Fault Diagnosis Time | Using high-speed CAN FD signal capture and protocol analysis, average fault diagnosis time is reduced by 30% |
| Improved Maintenance Accuracy | Accurately monitor ECU responses to reduce misjudgment risk and rework rate |
| Simplified Technician Training | Provides intuitive diagnostic workflow and reports, lowering the technical threshold and shortening training time for new technicians |
| Enhanced Customer Satisfaction | Fast and transparent maintenance reports increase customer trust and retention |
6. Extended Applications and Future Prospects
-
Integration with AI Fault Prediction Models
Utilize machine learning to analyze diagnostic data, providing early warnings for potential faults and improving preventive maintenance accuracy. -
Cloud-Based Diagnostic Database Development
Support cross-site data sharing and collaborative maintenance, while implementing high-standard data security and privacy protection mechanisms to ensure user data safety.
