UTP1025B

USB 轉印表機LPT接口轉換器
  • 支援標準IEEE1284雙向資料,速度高達每秒2.7MB
  • 符合標準USB-Printer Class,即插即用
  • 支援印表機最齊全
  • 支援USB 1.1全速12Mbps,USB 2.0相容
  • 超低電源功耗0.1W,不需額外供電
  • 全無鉛製程,符合環保RoHS 2等級要求
  • 支援Windows/ Mac/ Linux作業系統
  • 取得國際安規CE/FCC/VCCI認證
  • 台灣BSMI認證

介紹

SUNIX的COM Hub產品系列取得全球安規認證,是您最安心的選擇。UTP1025B USB轉印表機接口轉換器免安裝驅動程式,Printer Port支援SPP模式,傳輸速度高達12Mbps。支援市售印表機最齊全,Panasonic/EPSON/Cannon/Fujitsu/Sharp點矩陣印表機及其他相容印表機。

特點

備註:
* 不支援LPT Key Locker Parallel
* Windows和Linux作業系統不支援LPT port legacy 278/378 ISA address
* 本轉換器僅支援Printer Parallel device SPP模式

規格

USB傳輸

介面 通用串列Bus 連接器 USB Type A
標準 USB 1.1與USB 2.0相容 速度 全速12MBps

並列傳輸

介面 IEEE1284 SPP模式 IRQ & IO 系統分配
控制器 Prolific PL2305 速度 最高2.7MBps
埠數 1埠 連接器 DB25母頭

電源

輸入電源 USB Bus-power
功耗 <1W = 5V x 200mA

驅動支援

Windows Client 98/ME/2000/2003/2008/XP/Vista/7/8/10 (X86/X64)

認證

硬體 CE, FCC, VCCI, BSMI
軟體 Microsoft WHQL Windows XP

環境

操作溫度 0 °C 至 60 °C ( 32 °F 至 140 °F )
操作濕度 5% 至 95% RH
儲存溫度 -20 °C 至 85 °C ( -4°F 至 185 °F )

物理特徵

尺寸 75 (W) x 40 (D) x 22 (H) mm
外殼 ABS
重量 95 ± 5 g
Cable長度 1500 mm (5ft)

支援

使用手冊下載

使用手冊 UTP1025 manual
版本 Ver. 2.0
更新時間 2015-05-14 17:19:07
檔案大小 641.1KB

產品規格書下載

產品規格書 UTP1025B Datasheet

驅動程式下載

驅動程式 UTP1025 Windows Inbox Driver
作業系統
Windows 11 64bit
Windows 10 32/64 bit
Windows 8.1 32/64 bit
Windows 8.0 32/64 bit
Windows 7 SP1 32/64 bit
Windows XP SP3 32/64 bit
Windows Vista SP2 32/64 bit
Windows Server 2022 64bit
Windows Server 2019 64bit
Windows Server 2016 64bit
Windows Server 2012 R2 64-bit
Windows Server 2012 64bit
Windows Server 2008 R2 SP1 64bit
Windows Server 2008 32/64 bit
驅動程式 UTP1025 OS X Inbox Driver
作業系統
OS X 10.6 above
驅動程式 UTP1025 Linux Inbox Driver
作業系統
Linux 2.6.x above
