FWB3400T
1394B 2埠 & 1394A 1埠 PCI Express 擴充卡
- Supports PCI Express Base Specification Revision 1.1.
- Single-lane ( x1) PCI Express throughput rates up to 2.5 Gbps.
- Compliant with 1394 Open Host Controller Interface Ver1.1.
- Supports data transfer rates of 100, 200, 400 and 800Mbps.
- Provides 2 1394b external and 1 1394a sharing internal FireWire ports.
- Built-in SATA power connector for receiving extra power supply from system.
- Fully compliant with IEEE P1394b-2002 and backwards supports 1394a-2000 as well as 1394-1995 standards.
- Hot-swapping feature allows you to connect/disconnect devices without powering down the system.
- Works with various types of 1394 devices including DV camcorders, hard disk drives, removable drives, CD-RWs, DVD-ROMs and other 1394 audio/video devices
- Support Microsoft Windows 7,8/8.1,10, Linux system.
- Certified by CE, FCC, VCCI, BSMI, and RoHS.
介紹
SUNIX FWB3400T擴充卡使用T1 高品質處理晶片，提供您桌上型電腦IEEE1394B/A。IEEE1394B埠最高可提供800Mbps的高速傳輸，EEE1394A埠最高可提供400Mbps的高速傳輸。並且相容於最新PCI-Express 2.5Gb/s 速度插槽.讓您可以輕鬆使用目前最普遍的IEEE1394B/A 周邊 裝置例如：數位攝影機DV、數位相機、外接燒錄機、外接硬碟等產品，豐富你的數位影像生活。
規格
Hardware
| BUS | PCI Express Spec 3.0, Single-Lane (x1) |
| Controller | PCI Express to 1394b Host controller, XIO2213B |
| 1394 Standard | 1394 Open Host Controller Interface(OHCI)Specification ,Revision1.2 and Reversion 1.2 Draft. |
| IRQ & IO | Assigned by System |
1394 Communication
| Interface | 1394b x 2 ,1394a x 1 |
| Speed | Data transfer rate of 100/200/400/800M bit/s |
| No. of Port | 3 (1394b:2-port, 1394a:1-port) |
| PCB Connector | 1394b,1394a |
| Protection |
±8KV IEC61000-4-2 Air Gap Discharge ±4KV IEC61000-4-2 Contact Discharge |
Power
| Source | PCI Express bus power/SATA power 12V |
| Output Capacity |
1394a/b: 12V Note:Maximum total power output depends on the capacity of user’s power supply unit |
| Power Consumption | 0.74 W @3.3V and 12V(board only without power output to 1394 device) |
Driver Support
| Microsoft |
Windows 7 (X86/X64) Windows 8.x / 10 (X86/X64) (Windows in-box driver) |
| Linux | Linux 2.4x and 2.6x or later |
Environment
| Operation Temperature | 0 to 60°C (32 to 140°F) |
| Operation Humidity | 5 to 95% RH |
| Storage Temperature | -20 to 70°C (-4 to 158°F) |
Standards and Certifications
| EMC | CE, FCC, VCCI, BSMI |
| Green | RoHS, CRoHS, WEEE |
Physical Characteristics
| PCB Dimension | 65.3 x 68.5 mm |
| Bracket | Standard 121 mm, Low Profile 80mm |
| Bracket Space | 1 |
支援
產品規格書下載
| 產品規格書 | FWB3400T Datasheet |
|
快速安裝指南下載
| 快速安裝指南 | FWB3400T Quick Installation Guide |
|
驅動程式下載
| 驅動程式 | 1394 Windows Inbox Driver |
| 作業系統 |
Windows 10 32/64 bit
Windows 11 64bit
Windows Server 2022 64bit
Windows 8.1 32/64 bit
Windows 8.0 32/64 bit
Windows 7 SP1 32/64 bit
Windows XP SP3 32/64 bit
Windows Vista SP2 32/64 bit
Windows Server 2019 64bit
Windows Server 2016 64bit
Windows Server 2012 R2 64-bit
Windows Server 2012 64bit
Windows Server 2008 SP2 32/64 bit
|
| 驅動程式 | 1394 MAC Inbox Driver |
| 作業系統 |
OS X 10.4 above
|
| 驅動程式 | 1394 linux Inbox Driver |
| 作業系統 |
Linux 2.6.23 above
|
