介紹
三泰Serial ATA Gen3擴充卡系列採用高品質的MARVELL單晶片,支援所有SATA Ⅰ、Ⅱ、Ⅲ特色,共用和SATAⅠ、Ⅱ相同的傳輸纜線和連接器,6Gb/s高傳輸速率支援目前最新、最快的硬碟,並向下相容傳統SATA 1.5Gb/s、3Gb/s硬碟;,但要注意的是主板插槽須為PCI Express 2.0每個通道提供500MB/秒的輸出才能真正的增強系統效能,如果是PCI-Express 1.0下,反而降速無法發揮其強效。
規格
Description |
|
Product Description | Serial - ATA Ⅲ 6G 2-port PCI Express RAID Controller |
Serial Communication |
|
Interface | Single-Lane (x1) PCI Express Gen2 |
Controller | MARVELL |
Mode | Serial-ATA Generation- Ⅲ |
Port | One Internal SATA & One External SATA ports |
Speed | SATA III transfer rate of 6.0Gbps, 3.0Gbps 1.5Gbps |
O.S. support |
|
Windows 2000/XP/2003/Vista/7/8/8.1 (32/64-bit) ,Linux 2.6x, and DOS | |
Certifications |
|
CE, FCC, VCCI, BSMI | |
Environment |
|
Operation temp.: 0 °C ~ 57 °C Storage temp.: -20 °C ~ 85 °C Operation humidity: 5 ~ 95% RH |
|
Package Contents |
|
1. SATA1616 2. User Manual 3. CD Driver 4. Serial-ATA internal Cable 50cm (Optional) |
配件
選購配件

- Length : 50cm
- Partner No.: 1WST-A7050A12B0003
支援
使用手冊下載
使用手冊 | 771-SATA26000-002 |
![]() |
版本 | Ver 1.0 | |
更新時間 | 2013-05-16 10:27:53 | |
檔案大小 | 2.5MB |
產品規格書下載
產品規格書 | SATA1616 Datasheet V10 |
![]() |
驅動程式下載
驅動程式 | 9130_Utility_MSU_4.1.0.2023.zip | ![]() |
版本 | MSU_V4.1.0.2023 | |
更新時間 | 2015-01-23 09:40:23 | |
檔案大小 | 41.1MB | |
作業系統 |
Windows 8.1 32/64 bit
Windows 7 SP1 32/64 bit
Windows XP SP3 32/64 bit
Windows Server 2012 R2 64-bit
Windows Server 2008 R2 SP1 64bit
|
驅動程式 | 9130_V1.2.0.1041-WHQL | ![]() |
版本 | V1.2.0.1041 | |
更新時間 | 2015-01-23 09:37:41 | |
檔案大小 | 1.5MB | |
作業系統 |
Windows 8.1 32/64 bit
Windows 7 SP1 32/64 bit
Windows Server 2012 R2 64-bit
Windows Server 2008 R2 SP1 64bit
|
驅動程式 | driver 1.2.0.1014.zip | ![]() |
版本 | 1.2.0.1014 | |
更新時間 | 2011-12-15 14:40:17 | |
檔案大小 | 2.2MB | |
作業系統 |
Windows XP SP3 32/64 bit
|
介紹
三泰Serial ATA Gen3擴充卡系列採用高品質的MARVELL單晶片,支援所有SATA Ⅰ、Ⅱ、Ⅲ特色,共用和SATAⅠ、Ⅱ相同的傳輸纜線和連接器,6Gb/s高傳輸速率支援目前最新、最快的硬碟,並向下相容傳統SATA 1.5Gb/s、3Gb/s硬碟;,但要注意的是主板插槽須為PCI Express 2.0每個通道提供500MB/秒的輸出才能真正的增強系統效能,如果是PCI-Express 1.0下,反而降速無法發揮其強效。
規格
Description |
|
Product Description | Serial - ATA Ⅲ 6G 2-port PCI Express RAID Controller |
Serial Communication |
|
Interface | Single-Lane (x1) PCI Express Gen2 |
Controller | MARVELL |
Mode | Serial-ATA Generation- Ⅲ |
Port | One Internal SATA & One External SATA ports |
Speed | SATA III transfer rate of 6.0Gbps, 3.0Gbps 1.5Gbps |
O.S. support |
|
Windows 2000/XP/2003/Vista/7/8/8.1 (32/64-bit) ,Linux 2.6x, and DOS | |
Certifications |
|
CE, FCC, VCCI, BSMI | |
Environment |
|
Operation temp.: 0 °C ~ 57 °C Storage temp.: -20 °C ~ 85 °C Operation humidity: 5 ~ 95% RH |
|
Package Contents |
|
1. SATA1616 2. User Manual 3. CD Driver 4. Serial-ATA internal Cable 50cm (Optional) |
配件
選購配件

- Length : 50cm
- Partner No.: 1WST-A7050A12B0003
支援
使用手冊下載
使用手冊 | 771-SATA26000-002 |
![]() |
版本 | Ver 1.0 | |
更新時間 | 2013-05-16 10:27:53 | |
檔案大小 | 2.5MB |
產品規格書下載
產品規格書 | SATA1616 Datasheet V10 |
![]() |
驅動程式下載
驅動程式 | 9130_Utility_MSU_4.1.0.2023.zip | ![]() |
版本 | MSU_V4.1.0.2023 | |
更新時間 | 2015-01-23 09:40:23 | |
檔案大小 | 41.1MB | |
作業系統 |
Windows 8.1 32/64 bit
Windows 7 SP1 32/64 bit
Windows XP SP3 32/64 bit
Windows Server 2012 R2 64-bit
Windows Server 2008 R2 SP1 64bit
|
驅動程式 | 9130_V1.2.0.1041-WHQL | ![]() |
版本 | V1.2.0.1041 | |
更新時間 | 2015-01-23 09:37:41 | |
檔案大小 | 1.5MB | |
作業系統 |
Windows 8.1 32/64 bit
Windows 7 SP1 32/64 bit
Windows Server 2012 R2 64-bit
Windows Server 2008 R2 SP1 64bit
|
驅動程式 | driver 1.2.0.1014.zip | ![]() |
版本 | 1.2.0.1014 | |
更新時間 | 2011-12-15 14:40:17 | |
檔案大小 | 2.2MB | |
作業系統 |
Windows XP SP3 32/64 bit
|
介紹
三泰Serial ATA Gen3擴充卡系列採用高品質的MARVELL單晶片,支援所有SATA Ⅰ、Ⅱ、Ⅲ特色,共用和SATAⅠ、Ⅱ相同的傳輸纜線和連接器,6Gb/s高傳輸速率支援目前最新、最快的硬碟,並向下相容傳統SATA 1.5Gb/s、3Gb/s硬碟;,但要注意的是主板插槽須為PCI Express 2.0每個通道提供500MB/秒的輸出才能真正的增強系統效能,如果是PCI-Express 1.0下,反而降速無法發揮其強效。
規格
Description |
|
Product Description | Serial - ATA Ⅲ 6G 2-port PCI Express RAID Controller |
Serial Communication |
|
Interface | Single-Lane (x1) PCI Express Gen2 |
Controller | MARVELL |
Mode | Serial-ATA Generation- Ⅲ |
Port | One Internal SATA & One External SATA ports |
Speed | SATA III transfer rate of 6.0Gbps, 3.0Gbps 1.5Gbps |
O.S. support |
|
Windows 2000/XP/2003/Vista/7/8/8.1 (32/64-bit) ,Linux 2.6x, and DOS | |
Certifications |
|
CE, FCC, VCCI, BSMI | |
Environment |
|
Operation temp.: 0 °C ~ 57 °C Storage temp.: -20 °C ~ 85 °C Operation humidity: 5 ~ 95% RH |
|
Package Contents |
|
1. SATA1616 2. User Manual 3. CD Driver 4. Serial-ATA internal Cable 50cm (Optional) |
配件
選購配件

- Length : 50cm
- Partner No.: 1WST-A7050A12B0003
支援
使用手冊下載
使用手冊 | 771-SATA26000-002 |
![]() |
版本 | Ver 1.0 | |
更新時間 | 2013-05-16 10:27:53 | |
檔案大小 | 2.5MB |
產品規格書下載
產品規格書 | SATA1616 Datasheet V10 |
![]() |
驅動程式下載
驅動程式 | 9130_Utility_MSU_4.1.0.2023.zip | ![]() |
版本 | MSU_V4.1.0.2023 | |
更新時間 | 2015-01-23 09:40:23 | |
檔案大小 | 41.1MB | |
作業系統 |
Windows 8.1 32/64 bit
Windows 7 SP1 32/64 bit
Windows XP SP3 32/64 bit
Windows Server 2012 R2 64-bit
Windows Server 2008 R2 SP1 64bit
|
驅動程式 | 9130_V1.2.0.1041-WHQL | ![]() |
版本 | V1.2.0.1041 | |
更新時間 | 2015-01-23 09:37:41 | |
檔案大小 | 1.5MB | |
作業系統 |
Windows 8.1 32/64 bit
Windows 7 SP1 32/64 bit
Windows Server 2012 R2 64-bit
Windows Server 2008 R2 SP1 64bit
|
驅動程式 | driver 1.2.0.1014.zip | ![]() |
版本 | 1.2.0.1014 | |
更新時間 | 2011-12-15 14:40:17 | |
檔案大小 | 2.2MB | |
作業系統 |
Windows XP SP3 32/64 bit
|
SATA1616 (phased out)
2埠SATA Ⅲ 6G PCI Express RAID卡
- 擴充1外1內埠Serial ATA Gen 3, 向下相容SATA Ⅰ、Ⅱ
- 高速傳輸達6Gbps
- 相容PCI Express 2.0,並向下相容1.0規格
- 支援2個以上的存儲設備磁碟陣列組RAID 0, 1
- 硬體RAID設計,降低系統的資源負載
- 支援原生指令排序(NCQ)功能
- 支援不同品牌的大容量SATA硬碟
- 國際電磁相容性安規CE, FCC, VCCI, BSMI認證
- 符合綠色環保RoHS、WEEE規範
- 支援Microsoft Windows, Linux作業系統






三泰Serial ATA Gen3擴充卡系列採用高品質的MARVELL單晶片,支援所有SATA Ⅰ、Ⅱ、Ⅲ特色,共用和SATAⅠ、Ⅱ相同的傳輸纜線和連接器,6Gb/s高傳輸速率支援目前最新、最快的硬碟,並向下相容傳統SATA 1.5Gb/s、3Gb/s硬碟;,但要注意的是主板插槽須為PCI Express 2.0每個通道提供500MB/秒的輸出才能真正的增強系統效能,如果是PCI-Express 1.0下,反而降速無法發揮其強效。
介紹
三泰Serial ATA Gen3擴充卡系列採用高品質的MARVELL單晶片,支援所有SATA Ⅰ、Ⅱ、Ⅲ特色,共用和SATAⅠ、Ⅱ相同的傳輸纜線和連接器,6Gb/s高傳輸速率支援目前最新、最快的硬碟,並向下相容傳統SATA 1.5Gb/s、3Gb/s硬碟;,但要注意的是主板插槽須為PCI Express 2.0每個通道提供500MB/秒的輸出才能真正的增強系統效能,如果是PCI-Express 1.0下,反而降速無法發揮其強效。
規格
Description |
|
Product Description | Serial - ATA Ⅲ 6G 2-port PCI Express RAID Controller |
Serial Communication |
|
Interface | Single-Lane (x1) PCI Express Gen2 |
Controller | MARVELL |
Mode | Serial-ATA Generation- Ⅲ |
Port | One Internal SATA & One External SATA ports |
Speed | SATA III transfer rate of 6.0Gbps, 3.0Gbps 1.5Gbps |
O.S. support |
|
Windows 2000/XP/2003/Vista/7/8/8.1 (32/64-bit) ,Linux 2.6x, and DOS | |
Certifications |
|
CE, FCC, VCCI, BSMI | |
Environment |
|
Operation temp.: 0 °C ~ 57 °C Storage temp.: -20 °C ~ 85 °C Operation humidity: 5 ~ 95% RH |
|
Package Contents |
|
1. SATA1616 2. User Manual 3. CD Driver 4. Serial-ATA internal Cable 50cm (Optional) |
配件
選購配件

- Length : 50cm
- Partner No.: 1WST-A7050A12B0003
支援
使用手冊下載
使用手冊 | 771-SATA26000-002 |
![]() |
版本 | Ver 1.0 | |
更新時間 | 2013-05-16 10:27:53 | |
檔案大小 | 2.5MB |
產品規格書下載
產品規格書 | SATA1616 Datasheet V10 |
![]() |
驅動程式下載
驅動程式 | 9130_Utility_MSU_4.1.0.2023.zip | ![]() |
版本 | MSU_V4.1.0.2023 | |
更新時間 | 2015-01-23 09:40:23 | |
檔案大小 | 41.1MB | |
作業系統 |
Windows 8.1 32/64 bit
Windows 7 SP1 32/64 bit
Windows XP SP3 32/64 bit
Windows Server 2012 R2 64-bit
Windows Server 2008 R2 SP1 64bit
|
驅動程式 | 9130_V1.2.0.1041-WHQL | ![]() |
版本 | V1.2.0.1041 | |
更新時間 | 2015-01-23 09:37:41 | |
檔案大小 | 1.5MB | |
作業系統 |
Windows 8.1 32/64 bit
Windows 7 SP1 32/64 bit
Windows Server 2012 R2 64-bit
Windows Server 2008 R2 SP1 64bit
|
驅動程式 | driver 1.2.0.1014.zip | ![]() |
版本 | 1.2.0.1014 | |
更新時間 | 2011-12-15 14:40:17 | |
檔案大小 | 2.2MB | |
作業系統 |
Windows XP SP3 32/64 bit
|
